● Analog Output:
- 4 channels, 12 bit resolution
- Selectable unipolar or bipolar ranges 0-5V, 0-10V, ±5V, ±10V
- 100K conversions per second
- 3mA drive
● Digital Input/Output:
- 24 parallel bits (two 8 bit ports, two 4 bit ports)
- 64mA sink, 32mA source (ports A and B)
- I/O pulled up to 5V
- Change of state detect on port C
- Type 82C55 PPI mode 0 (1 and 2 optional)
- Industry Standard 50 pin header
● Timer/Counter: Type 82C54 (3×16 bit)
- Software Supported Modes:Three 16-Bit type 82C54；Event counter, Frequency output；Frequency and Pulse measurement
● I/O Connectors:
- Two Industry Standard 50 pin headers
● 0 to +70°C and -40 to +85°C versions available
● RoHS Available. Please contact us for ordering information
● Equipment monitoring
● Environmental measurements
● Embedded OEM
● Education/Laboratory
● Portable
● Industrial Automation
● Precision Measurement
● Analysis, Monitoring, and Control
The package includes a setup program detailing all jumper settings. Also included are IRQ drivers, samples for DOS, and utilities for Windows operating systems (XP -> 10, both 32 & 64 bit). Full register-level support for use in custom real-time or embedded operating systems.
