● 12-bit resolution A/D
● Broadly Configurable Arbitrary Waveform Generator (ARB)
● DACs Independently Programmable with Unique Waveforms
● 128K SRAM for ARB data storage
● Independent 12-bit D/A converter per channel
● DACs independently or simultaneously updated
● Output ranges of 0-5, 0-10, +/-5, +/-10V, corresponding 4-20mA output
● 32-bit counter for precisely timed outputs
● 16-bit counter for interrupt generation
● On-board DC/DC converter allows operation on +5V power
● Optional -40 to +85°C operating temperature
● Available in 4 and 8 channels, with or without the ARB
● RoHS Available. Please contact us for ordering information
● Industrial Equipment Control
● Waveform/Audio Synthesis
● Stimulus-Response
● Test
The 104-DA12-8A is supported for use in most operating systems and includes a free DOS, Linux and XP -> 10, both 32 & 64 bit compatible software package. This contains sample programs and source code in “C” for DOS, and Visual Basic, Delphi, and Visual C++ for Windows. Also incorporated is a graphical setup program and utilities to generate waveforms in Windows. Third-party support includes a Windows standard DLL interface usable from most popular application programs. Embedded OS support includes Windows Xpe, WES7, etc and CE. Linux support consists of installation files and basic samples for programming from user level via an open-source kernel driver.
