● PC/104
● Number of Inputs: Sixteen
● Type: Non-polarized, optically-isolated from each other and from the computer. (CMOS compatible).
● Voltage Range: 3 to 31V DC or AC RMS (50 to 10 KHz)
● Isolation: 500V
● Input Resistance: 1.8KΩ in series with opto-coupler.
● Response Time: 4.7 milliseconds w/filter, 10usec w/o filter
● Number of outputs: Four SPDT form C
● Contact Type: Single crossbar; Ag with Au clad
● Carry Current: 2A
● Rated Load AC: 0.5 A at 125 VAC (62.5 VA max )
● Rated Load DC: 1 A at 24 VDC ( 30 W max )
● Switch Voltage / Current: 125 VAC; 60 VDC / @ 1A (max)
● Contact Resistance: 100 mΩ max
● Max. Switching Voltage: 125 VA, 60 VDC
● Max. Switching Current: 1A
● Max. Carrying Current: 2A
● Contact Life-mechanical: 5,000,000 operations min
● Operating / Release Time: 5 ms max (mean value: approx 2.5 ms, and 0.9 ms respectively)
● When enabled by software, interrupts are generated when any digital input changes state (High to Low or Low to High, and from signal to no signal with AC inputs).
● +5VDC at 0.5A (all relays ON).
● Ambient Temperature: Operating: -30°C to 70°C. (non-icing)
● Weight: Approx. 4.5 oz. (~130 grams).
● This product is designed to be in full compliance with CE requirements.
