● 8 optically-isolated, non-polarized CMOS compatible digital inputs accept ±31VDC or AC rms
● IRQ on input change of state (COS) eliminates the need for constant polling
● Slow/fast filter to accommodate AC voltages and noisy DC inputs
● 8 long-life form C electro-mechanical relays switch up to 1A each
● 8 non-isolated TTL compatible inputs
● Factory Options:
- Economy version without COS feature
- Input only and relay only versions
- Expanded input voltage levels
● RoHS Available. Please contact us for ordering information
● Industrial Equipment Control
● Waveform/Audio Synthesis
● Stimulus-Response
● Test
The board is supported by most operating systems and include a free DOS, Linux and XP/2003/2008/7/8/8.1 compatible software package. This includes sample programs and source code in “C” for DOS, and Visual Basic, Delphi, and Visual C++ for Windows. Also included is a graphical setup program in Windows.
