● ISA Bus
● Receiver Input Sensitivity: ±200 mV, differential input
● Input Common Mode Voltage: -7V to +12V
● Transmitter Output Drive: 60 mA. Can drive 32-node, multidrop, two-wire, twisted-pair cable up to 4000 feet long.
● Serial Data Rates: Selectable, 300 baud to 115,200 baud, asynchronous.
● ±2.5 VDC, ±5.0 VDC, ±10.0 VDC
● I/O Bus Address (each port): DIP switch selectable within 100 to 3F8 (hex) range.
● Interrupts (each port): Jumper selectable, IRQ2-7, 10-12, 14, 15.
● Operating Temperature Range: 0° to 60°C.
● Storage Temperature Range: -40° to +100°C.
● Humidity: 0 to 90% RH, non-condensing.
● Full size card: 13.5 inches (343mm)
● 5 VDC at 400 mA typical, 800 mA maximum.
● This product is designed to be in full compliance with CE requirements.
