● PC/104-Plus (PCI-104 Optional)
● 48 or 96 Channel TTL-DTL high speed digital I/O
● Software selectable in vs. out as 8 bit and 4 bit ports
● Emulates 4 industry standard 8255 PPIs (mode 0)
● Full 32-bit PCI interface design
● Buffered circuits for higher driving capacity
● Low CPU overhead
● Known power-up states
● Output port status read back
● Standard 50-pin IDC connectors (x4)
● 0 to +70° C and -40 to +85° C versions available
● RoHS Available. Please contact us for ordering information
● Industrial Equipment Control
● Waveform/Audio Synthesis
● Stimulus-Response
● Test
Drivers for various operating systems are also provided, including active support for Windows XP -> 10 — all in both 32-bit and 64-bit flavors, and including consumer, server, and embedded varieties — as well as the 2.6 and newer Linux kernels and recent OSX / macOS versions. Many products continue to ship with driver support for Windows 95, 98, Me, NT4, and Windows 2000, but support for these operating systems is considered deprecated. ACCES is proud to provide a full suite of software support with every Data Acquisition product. We are committed to supporting the most popular operating systems and platforms for our customers. Currently we are actively supporting XP -> 10, both 32 & 64 bit, including “Server 2008,” “Embedded,” and “Compact” flavors for all plug-and-play products including PCI, PCI Express, USB, and more. Many products continue to ship with support for additional operating systems such as DOS, Windows 95, 98, Me, NT4, and 2000.
