● PCI Bus
● Logic High: 2.0 to 5.0 VDC
● Logic Low: -0.5 to +0.8 VDC
● Input Load (Hi): 20 μa
● Input Load (Lo): -200 μa
● Logic High: 2.0 VDC min., source 32 mA.
● Logic Low: 0.55 VDC max., sink 64 mA.
● +5 VDC from computer bus (ext. 1A fast-blow fuse recommended)
● +5 VDC @ 200 mA typical
● 6.9″ (175 mm) long
● Operating Temperature Range: 0° to 60°C
● Storage Temperature Range: -50° to +120°C
● Humidity: 0 to 90% RH, non-condensing.
● This product is designed to be in full compliance with CE requirements.
