● PCI Bus
● I/O Connection: 9 Pin DBM Connector.
● Character length: 5, 6, 7, or 8 bits.
● Stop Interval: 1, 1.5, or 2 bits.
● Serial Data Rates: Up to 115,200 baud, asynchronous. A faster range of rates, up to 460,800, is achieved by jumper selection on the card. Type 16550 buffered UART.
● Address: Continuously mappable within 0000 to FFFF (hex) range of PCI-bus addresses.
● Receiver Input Sensitivity: +200 mV, differential input.
● Common Mode Rejection: +12V to -7V.
● Transmitter Output Drive Capability: 60 mA, with thermal shutdown.
● Operating Temperature Range: 0 to +60°C.
● Storage: -25 to +85°C
● Humidity: 0 to 90 percent (non-condensing)
● +5VDC at 50 mA typical, +12VDC at 5 mA (Quiescent), 15 mA (Maximum).
● 4.80 inches long (122 mm).
● This product is designed to be in full compliance with CE requirements.
