● PCI Bus
● Number of inputs: 16.
● Type: Non-polarized, optically isolated from each other and from the computer.
● Input voltage range: 2.5 to 50V DC or 2-36VrmsAC (50 to 10000 Hz) with 0.2V hysteresis.
● Isolation: 500V*(see manual) channel to channel and channel to ground.
● Input Resistance: The opto-isolator diode current is constant at 4 mA typically regardless of input voltage.
● Interrupts: When enabled by software, interrupts are generated when any digital input changes state (High to Low or Low to High, and from signal to no signal or no signal to signal with AC inputs).
● Response Time: 5 mSec w/ filter.
● Number of outputs: Sixteen. In two groups of 8 channels each. In each group 4 channels are totally isolated and 4 channels have a common ground.
● Output Type: High Side Power MOS FET Switch. Protected against short circuit, over temperature, ESD, capable of driving inductive loads.
● Compliance Voltage: 5-34VDC (customer supplied).
● Current: 2A.
● Turn-on time: 90 usec (typical)
● Turn-off time: 110 usec (typical)
● Power Required: +5VDC at 0.250A.
● Operating Temperature: 0°C to +70°C
● Storage Temperature: -55°C to +150°C
● Humidity: 0% to 95% RH, without condensation
● Weight: Approx. 12 oz. (340 grams).
● Size: 6.8″ long (173 mm).
● This product is designed to be in full compliance with CE requirements.
