● PCI Bus
● Number of inputs: 16
● Type: Non-polarized, optically isolated from each other and from the computer. (not TTL/CMOS compatible)
● Voltage Range: 5 to 24V DC or AC (50 to 1000 Hz)
● Isolation: 500V*(see manual) channel to channel and channel to ground
● Input Resistance: 470 ohms in series with two diodes and an LED
● Response Time: 10 mSec w/filter, 20 uSec w/o filter
● Number of outputs: 16 (PCI-IIRO-16)
● Contact Rating: 2A carry current, bifurcated, gold clad, silver palladium
● Contact Arrangement:
- Channels 0-4 are SPDT Form C
- Channels 5-7 are SPST Form A
- Channels 8-12 are SPDT Form C
- Channels 13-15 are SPST Form A
● Contact Rating: Initial 100 milliohms maximum
● Contact Life: mech’l: 5 million operations minimum; elect’l: 5 million operations minimum at full load
● Operating Time: 2 milliseconds maximum
● Release Time: 1 milliseconds maximum
● Regulatory Approvals: UL and CSA
When enabled by software, interrupts are generated when digital inputs change state.
+5VDC @ @ 0.750 A (all relays ON) for PCI-IIRO-16
● Ambient PCI-IIRO-16 Temperature: Operating: 0 to +70°C Optional Industrial Version Operating: -30 to +70°C
● Storage: -40 to +85°C
● Humidity: 0 to 90 percent (non-condensing)
● Weight: Approx. 12 oz. (340 grams)
● Size: PCI-IIRO-16 is 6.8″ (173mm) long
● This product is designed to be in full compliance with CE requirements.
