● PCI Express
● I/O connection: VHDCI 68 pin SCSI connector
● Serial ports: 8 RS-232 ports
● Serial data rates: 460.8k baud (up to 921.6k baud) asynchronous
● UART: Octal type 16C950 with 128-byte transmit & receive FIFO, 16C550 compliant
● ESD Protection: ±15kV on all signal pins
● Character length: 5, 6, 7, or 8 bits
● Parity: Even, Odd, None, Space, Mark
● Stop interval: 1, 1.5, or 2 bits
● Flow Control: RTS/CTS and/or DSR/DTR, Xon/Xoff
● Cable: 3′ shielded breakout cable terminated with 8 male D-sub 9-pin connectors
● Operating Temperature 0° to +70°C
● Storage Temperature -40° to +105°C
● Humidity 5% to 95% RH, without condensation
● +3.3VDC @ 0.9W (typical)
● Board Dimension: 4.72″ (120mm) long by 2.20″ (55.8mm) high
