● PCI Express
● VCCIO 5V (TTL), optional 3.3V (LVTTL) on 50 pin header
● Logic High 2.0V to VCCIO
● Logic Low 0V to 0.8V
● Current ±20uA (max)
● Logic High 2.0V (min); 32mA source
● Logic Low 0.55V (max); 64mA sink
● Power Output VCCIO (P2 & P3; pin 49) Via 0.5A resettable fuse≤2μA
● Operating Temperature 0° to +70°C
● Storage Temperature -40° to +105°C
● Humidity 5% to 95% RH, without condensation
● Card Dimensions: 4.72″ (120mm) long by 4.20″ (106.7mm) high
● This product is designed to be in full compliance with CE requirements.
