● USB 2.0 Full-speed
● USB 3.1 Compatible
● USB 1.1 Compatible
● Operating Temperature Range: -40°C to +85°C
● Storage Temperature -40° to +85°C
● Humidity 5% to 95% , non-condensing
● Board Dimension: 3.550 x 3.775 inches
● Box Dimension: 4.00 x 4.00 x 1 inches
● ESD Protection: ±20kV on all signal pins (IEC 61000-4-2 Level 4)
● +5VDC @ ~ 120mA typical, high speed host, no active ports (does not include downstream ports USB device requirements)
● WI option: Wide Input power from 7VDC to 35VDC at the DC power jack or screw terminals
● Bus-powered @ ~ 100mA available for each downstream port (~400mA cumulative)
● Self-powered @ ~ 500mA available for each downstream port
The USB bus is specified to provide 500mA through the USB cable to most desktop environments. This gives you 380mA available on 5VDC (500mA – 120mA = 380mA) for any particular application. If using more than a total of 500mA, or your USB port has less then the 500mA normally provided, remove VUSB jumper and place jumper on VEXT. You may use three power input options (power jack, screw terminals, or 3.5” drive power connector (Berg). See manual for details.
● This product is designed to be in full compliance with CE requirements.
