● USB 2.0 Full-speed
● USB 3.1 Compatible
● USB 1.1 Compatible
● Operating Temperature Range: -40°C to +85°C
● Storage Temperature -40° to +85°C
● Humidity 5% to 95% , non-condensing
● Board Dimension: 3.550 x 3.775 inches
● Box Dimension: 3.985 x 3.990 x 1.045 inches
● Weight: 284.2 grams (in enclosure), 56.2 grams (-OEM version)
● External Power Supply: 0°C to 40°C (4kV isolation)
● External Power Required at the DC power jack or optional (-ST) screw terminal pair
● Our medical grade power supply: approximately 500 mA available for each downstream port with our medical grade isolated power supply
● WI option: Wide Input power from 7VDC to 35VDC
● Current-limiting: 0.85A typical per downstream port
● ESD Protection: ±20kV on all signal pins (IEC 61000-4-2 Level 4)
● Tru-Iso?: IPC-2221B, UL60590-1, UL1577 (4000V isolation meets EN60601)
● Up- to Downstream: 1500V peak (AC or DC)
● Max Transient Isolation: 4000V rms
● Max Work Isolation: 863V peak
● This product is designed to be in full compliance with CE requirements.
