● USB 2.0 Full-speed
● USB 3.1 Compatible
● USB 1.1 Compatible
● Operating Temperature Range: -40°C to +85°C
● Storage Temperature -40° to +85°C
● Humidity 5% to 95% , non-condensing
● Board Dimension: 2.350 x 2.381 inches
● Enclosure Dimension：
- 2.5 x 2.5 x 1 inches
- 2.5 x 3.5 x 1 inches with mounts
● Weight：
- 10 oz / 284.2 grams (in enclosure)
- 1.98 oz / 56.2 grams (-OEM version)
● Power Required: No external power required, 6mA min, up to 500mA from host when self-powered depending on downstream load
● Downstream: 380mA available when self-powered
● External Power: If external power supply is used, available downstream current is limited by external supply capacity
● ESD Protection: ±20kV on all signal pins (IEC 61000-4-2 Level 4)
● Tru-Iso?: IPC-2221B, UL60590-1, UL1577 (4000V isolation meets EN60601)
● Up- to Downstream: 1500V peak (AC or DC)
● Max Transient Isolation: 4000V rms
● Max Work Isolation: 863V peak
● This product is designed to be in full compliance with CE requirements.
