● PCI Bus
● Logic High: 2.0 to 5.0 VDC.
● Logic Low: -0.5 to +0.8 VDC.
● Input Load (Hi): 20 uA.
● Input Load (Lo): -200 uA.
● Logic High: 2.0 VDC min., source 32 mA.
● Logic Low: 0.55 VDC max., sink 64 mA.
● PCI-DIO-72: +5 VDC at 350 mA typical
● PCI-DIO-96: +5 VDC at 400 mA typical
● PCI-DIO-120: +5 VDC at 450 mA typical
● +5 VDC at 200 mA typical
● 12.2″ (310 mm) long
● Operating Temperature Range: 0° to 60°C
● Storage Temperature Range: -50° to +120°C
● Humidity: 0 to 90% RH, non-condensing.
● This product is designed to be in full compliance with CE requirements.
