● Universal PCI, PCI-X, 3.3V and 5V compatible(See the PCIe-DIO-120 page for the PCI-Express versions)
● Up to 120 channels of digital I/O
● All I/O lines buffered on the card
● Four- and eight-bit groups independently selectable for I/O on each 24-bit port
● Hysteresis correction and choice of pull-up and pull-down resistors on I/O lines
● Interrupt and interrupt-disable capability
● Tri-stateable I/O ports under software control
● +5V supply available to user
● Compatible with industry standard I/O racks like Gordos, Opto-22, Potter & Brumfield, Western Reserve Controls, etc.
● Automatically detected by Windows
● No base address or IRQ switches to set
● RoHS Available. Please contact us for ordering information
● Support for Wind River VxWorks (call for ordering information)
● Automatic Test Systems.
● Security Systems, Energy Management.
● Robotics.
● Relay Monitoring and Control.
● Parallel Data Transfer to PC.
● Sensing switch closures or TTL, DTL, CMOS Logic.
● Driving Indicator Lights or Recorders.
● Available accessories include a wide variety of cables and screw terminal boards for quick and easy connectivity.
Drivers for various operating systems are also provided, including active support for Windows XP -> 10 — all in both 32-bit and 64-bit flavors, and including consumer, server, and embedded varieties — as well as the 2.6 and newer Linux kernels and recent OSX / macOS versions. Many products continue to ship with driver support for Windows 95, 98, Me, NT4, and Windows 2000, but support for these operating systems is considered deprecated.
