● Number of Outputs: 8 channels
● Type of Outputs: Single-ended or differential
● Resolution: 12-bit resolution
● Unipolar Ranges: 0-2.5V, 0-5V, 0-10V
● Bipolar Ranges: ±2.5V, ±5V, ±10V
● Output Current: 6mA per channel
● Conversion Rate: buffered / non-streaming: 125K Samples per second x 8 channels.
● Conversion Rate: streaming: 400K samples per second TOTAL (ex: 25k Samples per second for 8 channels)
● Relative Accuracy: ±2 LSB typical
● Differential Non-linearity: ±0.2 LSB typical
● Settling Time: 8us typical, 10us max.
● Operating Temp.: 0° to 70°C
● Storage Temp.: -40° to +85°C
● Humidity: 5% to 95% non-condensing
● Board Dimension: 3.550 x 3.775 inches
● Box Dimension: 4 x 4 x 1.25 inches
● Power supplied via USB cable, or by an optional +5VDC regulated AC/DC power supply
● +5VDC @ ~200mA, typical (no load)
● ±12VDC supplied from +5VDC through DC/DC Converters
